BAG MAKING MACHINE BRAND SALDOFLEX MODEL MODULA S

BAG MAKING MACHINE

Model:
MODULA S
Year of construction:
2016/2017
Description:

BAG MAKING MACHINE BRAND SALDOFLEX MODEL MODULA S
YEAR 2016/2017
WIDTH 800
2 LINES

PRODUCTION  OF T-SHIRT  BAGS; BOTTOM SEALED BAGS (OPEN MOUTH BAGS) AND BLOCK NOTES BAGS UP TO TWO  LINES STARTING FROM ONE  PRINTED  OR  NOT  PRINTED  JUMBO ROLLS.

Technical data:

* maximum roll diameter : mm 1000.
* maximum film width :  mm 1200.
* maximum film lines  : 3.
* slit sealer knife by nickel chrome :  2.
* electric power supply :  400  Volts,   50 HZ  –  3 phases  +  earth
* total electric power installed  : 10.
* air compressed pressure :  ATE  6.
* air compressed consumption:  NL/1’
* maximum mechanical speed equipment:   mt/min.
* maximum production speed :  mt/min. up to
– max film thickness 60
– paint colour machine :  white and grey    (if not requested differently).
* net weight equipment : 1200  approx.



* minimum bag-length
-without pins stacking (for block bags)   :  mm.  235.
-with pins stacking (for t-shirt bags)  :  mm.  350.
* bag-length
– with   NON  STOP  DEVICE  :  mm. 700.
–  with   PAUSE DEVICE:  mm. 1200.
* welding width :  mm. 800.
* minimum welding thickness :  0.010 PE.HD.
* maximum welding thickness :  mm. 0.020 PE.LD.
* total welding thickness :  mm. 0.300.
* quantity of bags per stack : no. 100 according to film thickness and quality
* speed machine cycles/minute
-without pins stacking (for block bags)   :  no 180-200.
-with pins stacking (for t-shirt bags) : no   300.

Availability:
Disponibile
Price:
PU 34 - 22
